“IAM user, who can write to the S3 bucket”

Here we are to educate ourselves as to what “IAM user, who can write to the S3 bucket” is, by using cloudfront distribution and S3 objects, which are of world readable.

1.Create a bucket in s3 my-bucket

1. Log in to the AWS Management Console

2. Click on s3 tab

3. Create a new bucket

4. Create a custom/aws bucket policy to make it world readable

Read more…

Apache on the Cloud – The things you should know

    LAMP forms the base of most web applications.  As the load on an server increases, the bottlenecks in the underlying infrastructure become more apparent in the form of slow response to user requests.

     To overcome this slow response  the primary choice of most people is to add more hardware resources ( incase of AWS increasing the instance type). This will definitely  increases performance but will cost you more money.  The webserver and database eat most of the resources. Most commonly used web server is apache and database is MySQL. So if we can optimize these two we can improve the performance.

   Apache optimization techniques can often provide significant acceleration boosts  even when other acceleration techniques are in use, such as a CDN.  mod_pagespeed is a module from Google for Apache HTTP Servers that can improve the page load times of your website. you can read more on this from here.  If you want to deploy a PHP app on AWS Cloud, Its better to using some kind of caching mechanism.  Its already discussed in our blog .

      Once we came into a situation where we have to use a micro instance for a web server with less than 500 hits a day

      When the site started running live, and we feel like disappointed. when accessing website, it would sometimes pause for several seconds before serving the requested page. It took  hours to figure out what was going on. finally we run the command top and quickly discovered that when the site was accessing by certain amount of users the CPU would spike, but the spike was not the typical user or system CPU. For testing what’s happening in  server we used the apache benchmark tool ‘ab’ and run the following command on  localhost.

                                             #ab -n 100 -c 10 http://mywebserver.com/

      This will show  how fast our web server can handle 100 requests, with a maximum of 10 requests running concurrently. In the meantime we were monitoring the output of top command on web server.

     For further investigation we started with  sar – Linux command to  Collect, report, or save system activity information

  #sar 1

      According to amazon documentation “Micro instances (t1.micro) provide a small amount of consistent CPU resources and allow you to increase CPU capacity in short bursts when additional cycles are available”.

       If you use 100% CPU for more than a few minutes, Amazon will “steal” CPU time from the instance, meaning that they throttle your instance.  This last  as long as five minutes, and then you get a few seconds of 100% again, then the restrictions are back.  This will effect your website, making it slow, and even timing-out requests. basically means the physical hardware is busy and the hypervisor can’t give the VM the amount of CPU cycles it wants.

   Real tuning required on prefork. This is where we can tell apache to only generate so many processes. The defaults values  are high, and which cant be handled by micro instance. Suppose you get 10 concurrent requests for a php page and require around 64MB of RAM when requested (you have to make sure that  php memory_limit is above that value). That’s around 640MB of RAM on micro instance of 613MB RAM.  This is the case  with 10 connections – apache is configured to allow 256 clients by default,  We need to  scale these down , normally with 10-12 MaxClients. As per out case, this is still a huge number because 10-12 concurrent connections would use all our memory. If you want to be really cautious, make sure that your max memory usage is less than 613MB. Something like 64M php memory limit and 8 max clients keeps you under your limit with space to spare – this helps ensure that our MySQL process when your server is under load.

           Maxclients an important tuning parameter regarding the performance of the Apache web server. We can calculate the value of this for a t1.micro instance

Theoretically,

MaxClients =(Total Memory – Operating System Memory – MySQL memory) / Size Per Apache process.

t1.micro have a server with 613MB of Total memory. Suppose We are using RDS instead of mysql server.

Stop apache and run

#ps aux | awk ‘{sum1 +=$4}; END {print sum1}’.

 we will get the amount of memory thats used by processes other than apache.

Suppose we get a value around 30.

from top command we can check the average memory that each apache resources use.

suppose its 60mb.

Max clients = (613 – 30 ) 60 = 9.71 ~ 10 approx …

       Micro instances are awesome, especially when cost becomes a major concern, however that they are not right for all applications. A simple website with only a few hundreds  hits a day will do just fine since it will only need CPU in short bursts.

      For Servers that serves dynamic content, better approach is to employ a reverse-proxy. This would be done this apache’s mod_proxy or Squid. The main advantages of this configurations are content caching, load balancing etc. Easy method is to use mod_proxy and the ProxyPass directive to pass content to another server. mod_proxy supports a degree of caching that can offer a significant performance boost. But another advantage is that since the proxy server and the web server are likely to have a very fast interconnect, the web server can quickly serve up large content, freeing up a apache process, why the proxy slowly feeds out the content to clients

If you are using ubuntu, you can enable module by

                                        #a2enmod proxy

                                        #a2enmod proxy_http

and in apache2.conf

                                         ProxyPass  /  http://192.168.1.46/

                                         ProxyPassReverse  /   http://192.168.1.46/

         The ProxyPassreverse directive captures the responses from the web server and masks the URL as it would be directly responded by the Apache  hiding the identity/location of the web server. This is a good security practice, since the attacker won’t be able to know the ip of our web server.

      Caching with Apache2 is another important consideration.  We can configure apache  to set the Expires HTTP header, max-age directive of the Cache-Control HTTP header of static files ,such as images, CSS and JS files, to a date in the future so that these files will be cached by your visitors browsers. This saves bandwidth and makes web site appear faster if a user visits your site for a second time, static files will be fetched from the browser cache

                                      #a2enmod expires

  edit  /etc/apache2/sites-available/default

  <IfModule mod_expires.c>
               ExpiresActive On
               ExpiresByType image/gif “access plus 4 weeks”
               ExpiresByType image/jpg “access plus 4 weeks”

</IfModule>

This would tell browsers to cache .jpg, .gif  files for four week.

       If your server requires a large amount of read / write operations, you might consider provisioned IOPS ebs volumes on your server. This is really effective if you use database server on ec2 instances.  we can use iostat on the command line to take a look at your read/sec and write/sec. You can also use CloudWatch metrics to determine read and write operations.

       Once we move to the security side of apache, our major concern is DDos attacks. If a server is under a DDoS attack, it is quite difficult to detect the attack before the damage is done.  Attack packets usually have spoofed source IP addresses. Hence, it is more difficult to trace them back to their real source. The limit on the number of simultaneous requests that will be served by Apache is decided by the MaxClients directive, and is set to safe limit, by default. Any connection attempts over this limit will normally be queued up.

     If you want to protect your apache against DOS,  DDOS attacks use mod_evasive module.  This module is designed specifically as a remedy for Apache DoS attacks. This module will allow you to specify a maximum number of requests executed by the same IP address. If the limit is reached, the IP address is blacklisted for the time period you specify.

php Caching.., The way to speed up php sites.

     There are many sites which  is built in PHP. PHP provides the power to simply ‘pull’ content from an external source.   it could just as easily be an MySQL database or an XML file etc.

    The downside to this is processing time, each request for one page can trigger multiple database queries, processing of the output, and formatting it for display. This can be quite slow on complex sites (or slower servers).  Dynamic sites probably have very little changing content, this page will almost never be updated after the day it is written. Each time someone requests it the scripts goes and fetches the content, applies various functions and filters to it, then outputs it to you

       This is where caching can help us out, instead of regenerating the page every time, the scripts running this site generate it the first time they’re asked to, then store a copy of what they send back to your browser. The next time a visitor requests the same page, the script will know it’d already generated one recently, and simply send that to the browser without all the hassle of re-running database queries or searches.

Different Caching mechanism are discussed below.

APC

      APC stands for Alternative PHP Cache, and is a free and open opcode cache for PHP. It provides a robust framework for caching and optimizing PHP performance. APC also provides a user cache for storing application data. APC for caches that do not change often and will not grow too big to avoid fragmentation. The default setting of APC will allow you to store 32 MiB for the opcode cache and the user cache combined

Installing apc on ubuntu

#apt-get install php-apc

edit  apc.ini   ; default location on new php5 is –> /etc/php5/conf.d/20-apc.ini

extension = apc.so;  uncomment this line
apc.shm_segments=1;   ( by default its enabled .. give 0 to disable)

you can customize your values here. for getting the default values install php5-cli and from command line run

#php -i | grep apc

For monitoring apc cache hits and miss, apc providing a php script. which is located at /usr/share/doc/php-apc/apc.php. Copy this file to your document root and you will be able to monitor your apc status.

http://localhost/apc.php

for performance benchmarking we created two php files

test1.php

<?php
         $start = microtime(true);
         for ($i = 0; $i < 500000; $i++)
             {
                include('test_include.php');
             }
         $end = microtime(true);          echo "Start: " . $start . "<br />";
         echo "End: " . $end . "<br />";
         echo "Diff: ". ($end-$start) . "<br />";
?>

test2.php

<?php
          $t =    "migrate2cloud";
 ?>

Without apc…

Start: 1360937874.8965
End: 1360937883.1506
Diff: 8.2541239261627

With apc..

Start: 1360937935.5746
End: 1360937936.7291
Diff: 1.1545231342316

 without apc it took 8 seconds to complete the request .. with apc.. 1.15 seconds..

Memcached

        Memcached system uses a client–server architecture. The servers maintain a key–value associative array; the clients populate this array and query it. Keys are up to 250 bytes long and values can be at most 1 megabyte in size. Clients use client-side libraries to contact the servers which, by default, expose their service at port 11211. Amazon provides a Service called Amazon elasticache for memcache through which we can configure memcache clusters for caching purposes.

installation and configuration

apt-get install memcached
apt-get install php5-memcached

enable memcache module in /etc/php5/apache2/conf.d/20-memcached.ini  or in php.ini

edit php.ini
session.save_handler = memcached
extension=memcache.so
extension=memcached.so

Restart apache and memcache..

php script used for memcache testing..


<?php
//memcached simple test
$memcache = new Memcache;
$memcache->connect('localhost', 11211) or die ("Could not connect");
$key = md5('42data');  //something unique
for ($k=0; $k<5; $k++) {
$data = $memcache->get($key);
    if ($data == NULL) {
       $data = array();
       //generate an array of random shit
       echo "expensive query";
       for ($i=0; $i<100; $i++) {
           for ($j=0; $j<10; $j++) {
               $data[$i][$j] = 42;  //who cares
           }
       }
       $memcache->set($key,$data,0,3600);
    } else
 {
       echo "cached";
    }  }

You can monitor memcache using phpmemcacheadmin

http://code.google.com/p/phpmemcacheadmin/

Varnish – Cache

Varnish has a concept of “backend” or “origin” servers. A backend server is the server providing the content Varnish will accelerate. Our first task is to tell Varnish where it can find its content. open the varnish default configuration file. Iif you installed from a package it is probably /etc/varnish/default.vcl.

Somewhere in the top there will be a section that looks a bit like this.:

backend default { .host = "127.0.0.1"; .port = "80"; }

Change the port number to your apache ( or whatever the webserver you are using) port number.

this piece of configuration defines a backend in Varnish called default. When Varnish needs to get content from this backend it will connect to port 80 on localhost (127.0.0.1).

# varnishd -f /etc/varnish/default.vcl -s malloc,1G -T 127.0.0.1:2000 -a 0.0.0.0:80

The -f options specifies what configuration varnishd should use.

The -s options chooses the storage type Varnish should use for storing its content

-T 127.0.0.1:2000 — Varnish has a built-in text-based administration interface

-a 0.0.0.0:80 — specify that I want Varnish to listen on port 80

For logging varnish — In terminal window you started varnish type varnishlog

When someone accessing your page you will get log like

#varnishlog
11 SessionOpen c 127.0.0.1 58912 0.0.0.0:80
11 ReqStart c 127.0.0.1 58912 595005213
11 RxRequest c GET
11 RxURL c /
11 RxProtocol c HTTP/1.1
11 RxHeader c Host: localhost:80
11 RxHeader c Connection: keep-alive

Where not to use Caching

          Caching should not be used for some things like search results, forums etc… where the content has to be upto the times and changes depending on user’s input. It’s also advisable to avoid using this method for things like a Flash news page, in general dont use it on any page that you wouldn’t want the end users browser or proxy to cache.

Migrate Mysql database to Mongodb

In recent years, we have seen a growing interest in database management systems that differ from the traditional relational model. At the heart of this is the concept of NoSQL, a term used collectively to denote database software that does not use the Structured Query Language (SQL) to interact with the database. One of the more notable NoSQL projects out there is MongoDB, an open source document-oriented database that stores data in collections of JSON-like documents. What sets MongoDB apart from other NoSQL databases is its powerful document-based query language, which makes the transition from a relational database to MongoDB easy because the queries translate quite easily.

This new class of databases seems to solve many of the bottlenecks in MySql and other relational databases. It will give you shear performance, self replication and scalability at not cost because it open source. MongoDB has plenty of drivers for other scripting and high-level languages I use PHP so I download the PHP driver. You can see the supported list here: http://www.mongodb.org/display/DOCS/Drivers. In this blog I convert  a MySQL database using PHP to MongoDB.

First you install MongoDB, you can do it by checking the previous blog.  Check this link

Then we run the script to convert a Mysql DB to Mongodb.

create a new file called MySqltoMongodb.php , In that file please copy paste the below contants (please give your Mysql DB details as well as your Mongodb details)

  1. <?php
  2. // mysql settings
  3. $mydb = “database”;
  4. $myconn = mysql_connect(‘localhost’,’user’,’password’);
  5. $setmydb = mysql_select_db( $mydb );
  6. $mytables = getMyTables( $mydb );
  7.  //mongo db settings
  8. $modb = “database”;
  9. $moConnect=”mongodb://user:password@localhost”;
  10.  function getMyTables( $dbname ) {
  11. $tables = array();
  12. $sql = mysql_query(“SHOW TABLES FROM $dbname “) or die(“Error getting tables from $dbname”);
  13.  if( mysql_num_rows( $sql ) > 0 ) {
  14. while( $table = mysql_fetch_array( $sql ) ) {
  15. $explain = explainMyTable( $table[0] );
  16. $tables[$table[0]] = $explain;
  17. }
  18. }
  19. return $tables;
  20. }
  21.  function explainMyTable( $tbname ) {
  22. $explain = array();
  23. $sql = mysql_query(“EXPLAIN $tbname”) or die(“Error getting table structure”);
  24. $i = 0;
  25.  while( $get = mysql_fetch_array( $sql ) ) {
  26. array_push( $explain, $get[0] );
  27. $i++;
  28. }
  29. return $explain;
  30. }
  31.  function checkEncode($string) {
  32. if( !mb_check_encoding($string,’UTF-8′)) {
  33. return mb_convert_encoding($string,’UTF-8′,’ISO-8859-1′);
  34. } else {
  35. return $string;
  36. }
  37.  }
  38. try {
  39. $moconn = new Mongo($moConnect);
  40. $modb = $moconn->selectDB( $modb );
  41. } catch(MongoConnectionException $e) {
  42. die($e.”Problem during mongodb initialization. Please start mongodb server.”);
  43. }
  44.  foreach( $mytables as $table => $struct ) {
  45. $sql = mysql_query(“SELECT * FROM $table LIMIT 0 , 500000″) or die( mysql_error() );
  46. $count = mysql_num_rows( $sql );
  47.  // Starts new collection on mongodb
  48. $collection = $modb->$table;
  49.  // If it has content insert all content
  50. if( $count > 0 ) {
  51. while( $info = mysql_fetch_array( $sql, MYSQL_NUM )) {
  52. $infosize = count( $info );
  53. $mosql = array();
  54.  for( $i=0; $i < $infosize; $i++ ) {
  55. if(!empty($struct[$i]))
  56. $mosql[$struct[$i]] = checkEncode($info[$i]);
  57. }
  58.  $collection->insert($mosql);
  59. }
  60. // Only create a new entry empty
  61. } else {
  62.  for( $i=0; $i < $infosize; $i++ ) {
  63. if(!empty($struct[$i]))
  64. $mosql[$struct[$i]] = ”;
  65.  }
  66. $collection->insert($mosql);
  67. }
  68. }
  69. echo “Done! Please, check your MongoDB collection!”;
  70. ?>

Now fire up your browser and launch the page. If all goes well you should see
“Done! Please, check your MongoDB collection!”

After running this script check your Mongo db collection, in that you can see your Mysql Table.  However we haven’t done it on a large system, we are planning to do the same on a huge Postgres Sql system soon.

Installation of MongoDB and its performance test

Why MongoDB?

  • Document-oriented
    • Documents (objects) map nicely to programming language data types
    • Embedded documents and arrays reduce need for joins
    • Dynamically-typed (schemaless) for easy schema evolution
    • No joins and no multi-document transactions for high performance and easy scalability
  • High performance
    • No joins and embedding makes reads and writes fast
    • Indexes including indexing of keys from embedded documents and arrays
    • Optional streaming writes (no acknowledgements)
  • High availability
    • Replicated servers with automatic master failover
  • Easy scalability
    • Automatic sharding (auto-partitioning of data across servers)
    • Reads and writes are distributed over shards
    • No joins or multi-document transactions make distributed queries easy and fast
    • Eventually-consistent reads can be distributed over replicated servers

Mongo data model

  • A Mongo system (see deployment above) holds a set of databases
  • A database holds a set of collections
  • A collection holds a set of documents
  • A document is a set of fields
  • A field is a key-value pair
  • A key is a name (string)
  • A value is a
    • basic type like string, integer, float, timestamp, binary, etc.,
    • a document, or
    • an array of value

    Mongo query language

  • To retrieve certain documents from a db collection, you supply a query document containing the fields the desired documents should match. For example, {name: {first: 'John', last: 'Doe'}} will match all documents in the collection with name of John Doe. Likewise, {name.last: 'Doe'} will match all documents with last name of Doe. Also, {name.last: /^D/} will match all documents with last name starting with ‘D’ (regular expression match).
  • Queries will also match inside embedded arrays. For example, {keywords: 'storage'} will match all documents with ‘storage’ in its keywords array. Likewise, {keywords: {$in: ['storage', 'DBMS']}} will match all documents with ‘storage’ or ‘DBMS’ in its keywords array.
  • If you have lots of documents in a collection and you want to make a query fast then build an index for that query. For example, ensureIndex({name.last: 1}) or ensureIndex({keywords: 1}). Note, indexes occupy space and slow down updates a bit, so use them only when the tradeoff is worth it.

Install MongoDB on Ubuntu 10.04

Configure Package Management System (APT)

The Ubuntu package management tool (i.e. dpkg and apt) ensure package consistency and authenticity by requiring that distributors sign packages with GPG keys. Issue the following command to import the 10gen public GPG Key:

sudo apt-key adv --keyserver keyserver.ubuntu.com --recv 7F0CEB10

Create a /etc/apt/sources.list.d/10gen.list file and include the following line for the 10gen repository.

deb http://downloads-distro.mongodb.org/repo/ubuntu-upstart dist 10gen

Now issue the following command to reload your repository:

sudo apt-get update

Install Packages

Issue the following command to install the latest stable version of MongoDB:

sudo apt-get install mongodb-10gen

When this command completes, you have successfully installed MongoDB! Continue for configuration and start-up suggestions.

Configure MongoDB

These packages configure MongoDB using the /etc/mongodb.conf file in conjunction with the control script. You will find the control script is at /etc/init.d/mongodb.

This MongoDB instance will store its data files in the /var/lib/mongodb and its log files in /var/log/mongodb, and run using the mongodb user account.

Note

If you change the user that runs the MongoDB process, you will need to modify the access control rights to the /var/lib/mongodb and /var/log/mongodb directories.

Controlling MongoDB

Starting MongoDB

You can start the mongod process by issuing the following command:

sudo service mongodb start

You can verify that mongod has started successfully by checking the contents of the log file at /var/log/mongodb/mongodb.log.

Stopping MongoDB

As needed, you may stop the mongod process by issuing the following command:

sudo service mongodb stop

Restarting MongoDB

You may restart the mongod process by issuing the following command:

sudo service mongodb restart

Controlling mongos

As of the current release, there are no control scripts for mongos. mongos is only used in sharding deployments and typically do not run on the same systems where mongod runs. You can use the mongodb script referenced above to derive your own mongos control script.

Using MongoDB

Among the tools included with the MongoDB package, is the mongo shell. You can connect to your MongoDB instance by issuing the following command at the system prompt:

mongo
> show dbs (); —> To show your databases
> use <databasename> —-> To switch database
> db.createCollection(“collectionname”) —> To create collection
> db.collectionname.find(); —> To see the contents in the collection
> db.addUser(“theadmin”, “anadminpassword”) —> To create user and password

Mongodb performance test :-

To monitor database system we can use Mongotop

Mongotop tracks and reports the current read and write activity of a MongoDB instance.
Mongotop provides per-collection visibility into use.
Use mongotop to verify that activity and use match expectations.
Mongotop returns time values specified in milliseconds (ms.)
Mongotop only reports active namespaces or databases, depending on the –locks option.
If you don’t see a database or collection, it has received no recent activity.

By default mongotop connects to the MongoDB instance running on the localhost port 27017. However,mongotop can optionally connect to remote mongod instances

Next, we can use Mongostat

Mongostat captures and returns counters of database operations. Mongostat reports operations on a per-type (e.g. insert, query, update, delete, etc.) basis. This format makes it easy to understand the distribution of load on the server. Use  Mongostat to understand the distribution of operation types and to inform capacity planning.
The Mongostat utility provides a quick overview of the status of a currently running mongod or Mongos instance. Mongostat is functionally similar to the UNIX/Linux file system utility vmstat, but provides data regarding mongod and Mongos instances.

Use  db.serverStatus()
It provides an overview of the database process’s state.

Then REST interface

MongoDB provides a REST interface that exposes a diagnostic and monitoring information in a simple web page. Enable this by setting rest to true, and access this page via the local host interface using the port numbered 1000 more than that the database port. In default configurations the REST interface is accessible on 28017. For example, to access the REST interface on a locally running mongod instance: http://localhost:28017

These are a few basic tips on making your application better/faster/stronger without knowing anything about indexes or sharding.

Connecting

Connecting to the database is a (relatively) expensive operation. Try to minimize the number of times you connect and disconnect: use persistent connections or connection pooling (depending on your language).

there are some  side effects with the PHP connection code.

$connection = new Mongo ( );

$connection->connect( );

In this code it appears the user wants to create a new connection. However, under the hood the following is happening:

The constructor connects to the database.
connect( ) sees that you’re already connected, assumes you want to reset the connection.
Disconnects from the database.
Connects again.

The result is that you have doubled your execution time.

ObjectIds

ObjectIds seem to be uncomfortable, so they convert their ObjectIds into strings. The problem is, an ObjectId takes up 12 bytes but its string representation takes up 29 bytes (almost two and a half times bigger).

Numbers vs. Strings

MongoDB is type-sensitive and it’s important to use the correct type: numbers for numeric values and strings for strings.

If you have large numbers and you save them as strings (“1234567890″ instead of 1234567890), MongoDB may slow down as it strcmps the entire length of the number instead of doing a quicker numeric comparison. Also, “12″ is going to be sorted as less than “9″, because MongoDB will use string, not numeric, comparison on the values. This can lead to some errors.

Driver-specific
Find out if you’re driver is particularly weaknesses (or strengths). For instance, the Perl driver is one of the fastest drivers, but it is not good at decoding Date types (Perl’s DateTime objects take a long time to create).
MongoDB adopts a documented-oriented format, so it is more similar to RDBMS than a key-value or column oriented format.

MongoDB operates on a memory base and places high performance above data scalability.Mongo DB uses BSON for data storage

Mongo uses memory mapped files, which means that a lot of the memory reported by tools such as top may not actually represent RAM usage. Check mem["resident"], which tells you how much RAM Mongo is actually using.

“mem” : {
    “resident” : 2,
    “virtual” : 2396,

    “supported” : true,
    “mapped” : 0
},

Backup

There are basically two approaches to backing up a Mongo database:

Mongodump and Mongorestore are the classic approach. Dumps the contents of the database to files. The backup is stored in the same format as Mongo uses internally, so is very efficient. But it’s not a point-in-time snapshot.
To get a point-in-time snapshot, shut the database down, copy the disk files (e.g. with cp) and then start mongod up again. Alternatively, rather than shutting mongod down before making your point-in-time snapshot, you could just stop it from accepting writes:

> db._adminCommand({fsync: 1, lock: 1})
{
        “info” : “now locked against writes, use db.$cmd.sys.unlock.findOne() to unlock”,

        “ok” : 1
}

To unlock the database again, you need to switch to the admin database and then unlock it

> use admin
switched to db admin
> db.$cmd.sys.unlock.findOne()
{ “ok” : 1, “info” : “unlock requested” }

Replication
Start your master and slave up like this:

$ mongod –master –oplogSize 500

$ mongod –slave –source localhost:27017 –port 3000 –dbpath /data/slave

When seeding a new slave server from master use the –fastsync option.

You can see what’s going on with these two commands:
> db.printReplicationInfo() # tells you how long your oplog will last
> db.printSlaveReplicationInfo() # tells you how far behind the slave is

If the slave isn’t keeping up,Check the mongo log for any recent errors. Try connecting with the mongo
console. Try running queries from the console to see if everything is working. Run the status commands
above to try and find out which database is taking up resources.
Timeout

Connection timeout in milliseconds. Defaults to 20000

Connection::query_timeout.

How many milliseconds to wait for a response from the server. Set to 30000 (30 seconds) by default. -1 waits forever (or until TCP times out, which is usually a long time).

Default pool

The default pool has a maximum of 10 connections per mongodb host. This value is controlled by the variable  “connectionsPerHost” within the class

MongoDB Server Connections

The MongoDB server has a property called “maxConns” that  is the max number of simultaneous connections. The
default number for maxConns is 80% of the available file descriptors for connections. One way to check the number of connections is by opening the mongo shell and executing:

>db.serverStatus() and in the previous mail I have send the screen shot of this.

The standard format of the MongoDB connection URI used to connect to a MongoDB database server.

mongodb://[username:password@]host1[:port1][,host2[:port2],…[,hostN[:portN]]][/[database][?options]]

Finding the Min and Max values in MongoDB

In MongoDB, the min() and max() functions work as limitors – essentially the same as “gte” (>=) and “lt” (<).

To find the highest (maximum) value in MongoDB, you can use this command;

db.thiscollection.find().sort({“thisfieldname”:-1}).limit(1)

This essentially sorts the data by the fieldname in decending and takes the first value.

The lowest (minimum) value can be determined in a similar way.

    db.thiscollection.find().sort({“thisfieldname”:1}).limit(1)

Memory Mapped Storage Engine :-

This is the current storage engine for MongoDB, and it uses memory-mapped files for all disk I/O.  Using this strategy, the operating system’s virtual memory manager is in charge of caching.  This has several implications:

There is no redundancy between file system cache and database cache: they are one and the same.
MongoDB can use all free memory on the server for cache space automatically without any configuration of a cache size.
Virtual memory size and resident size will appear to be very large for the mongod process.

This is benign: virtual memory space will be just larger thanthe size of the datafiles open and mapped; resident size will vary depending on the amount of memory not used by other processes on the machine.

This command shows the memory usage information :- db.serverStatus().mem

For example :-

> db.serverStatus().mem
{
    “bits” : 64,
    “resident” : 31,
    “virtual” : 146,
    “supported” : true,
    “mapped” : 0,
    “mappedWithJournal” : 0
}

We can verify there is no memory leak in the mongod process by comparing the mem.virtual and mem.mapped values (these values are in megabytes).  If you are running with journaling disabled, the difference should be relatively small compared to total RAM on the machine. If you are running with journaling enabled, compare mem.virtual to 2*mem.mapped.   Also watch the delta over time; if it is increasing consistently, that could indicate a leak.

Also we can use to check what percent of memory is being used for memory mapped files by the free command:

Here 2652mb of memory is being used to memory map files

root@manager-desktop:~# free -tm

             total       used       free     shared    buffers     cached
Mem:          3962       3602        359          0        411       2652

-/+ buffers/cache:        538       3423

Swap:        1491        52       1439

Total:        5454       3655   1799

Garbage collection handling :-

When we remove an object from MongoDB collection, the space it occupied is not automatically garbage collected and new records are only appended to the end of data files, making them grow bigger and bigger.MongoDB maintains lists of deleted blocks within the datafiles when objects or collections are deleted.  This space is reused by MongoDB but never freed to the operating system.

To shrink the amount of physical space used by the datafiles themselves, by reclaiming deleted blocks, we must rebuild the database by using  the command “db.repairDatabase( )” . repairDatabase copies all the database records to new files.

We will need enough free disk space to hold both the old and new database files while the repair is running, the repairDatabase  will take a long time to complete.Also rather than compacting an entire database,

you can compact just a single collection by using  “db.runCommand({compact:’collectionmname;})

This does not shrink any datafiles,however; it only defragments deleted space so that larger objects might reuse it.

The compact command will never delete or shrink database files, and in general requires extra space to do its work.

Thus, it is not a good option when you are running critically low on disk space.

Make your websites run faster, automatically — try mod_pagespeed for Apache

Google just released the first stable version of mod_pagespeed, the company’sopen-source module for Apache that can automatically optimize your  web pages to improve download and rendering speeds. With this release, Google is declaring this tool ready for broader adoption, though it’s worth noting that a number of large hosting providers like DreamHost, Go Daddy and content delivery network EdgeCast have already been using it in production for quite a while now.

“mod_pagespeed” speeds up your site and reduces page load time. This open-source Apache HTTP server module automatically applies web performance best practices to pages, and associated assets (CSS, JavaScript, images) without requiring that you modify your existing content or workflow.

FEATURES:-

1. Automatic website and asset optimization

2. Latest web optimization techniques

3. 40+ configurable optimization filters

4. Free, open-source, and frequently updated

5. Deployed by individual sites, hosting providers, CDN’s

How does mod_pagespeed speed up web-sites?

“mod_pagespeed” improves web page latency and bandwidth usage by changing the resources on that web page to implement web performance best practices. Each optimization is implemented as a custom filter in mod_pagespeed, which are executed when the Apache HTTP server serves the website assets. Some filters simply alter the HTML content, and other filters change references to CSS, JavaScript, or images to point to more optimized versions.

“mod_pagespeed” implements custom optimization strategies for each type of asset referenced by the website, to make them smaller, reduce the loading time, and extend the cache lifetime of each asset. These optimizations include combining and minifying JavaScript and CSS files, inlining small resources, and others. mod_pagespeed also  dynamically optimizes images by removing unused meta-data from each file, resizing the images to specified dimensions, and re-encoding images to be served in the most efficient format available to the user.

“mod_pagespeed” ships with a set of core filters designed to safely optimize the content of your site without affecting the look or behavior of your site.   In addition, it provides a number of more advanced filters which can be turned on by the site owner to gain higher performance improvements.

“mod_pagespeed” can be deployed and customized for individual web sites, as well as being used by large hosting providers and CDN’s to help their       users improve performance of their sites, lower the latency of their pages, and decrease bandwidth usage.

Installing mod_pagespeed on CentOS (cPanel/WHM)

  1. root@server1# cd /usr/src
  2. root@server1[/usr/src]# mkdir mod_pagespeed/
  3. root@server1[/usr/src]# cd mod_pagespeed
  4. root@server1[/usr/src/mod_pagespeed]# wget https://dl-ssl.google.com/dl/linux/direct/mod-pagespeed-beta_current_x86_64.rpm
  5. root@server1[/usr/src/mod_pagespeed]# rpm2cpio mod-pagespeed-beta_current_x86_64.rpm | cpio -idmv
  6. root@server1[/usr/src/mod_pagespeed]# cp usr/lib/httpd/modules/mod_pagespeed.so /usr/local/apache/modules
  7. root@server1[/usr/src/mod_pagespeed]# chmod 755 /usr/local/apache/modules/mod_pagespeed.so
  8. root@server1[/usr/src/mod_pagespeed]# mkdir -p /var/mod_pagespeed/{cache,files} —–> Create pagespeed directories.
  9. root@server1[/usr/src/mod_pagespeed]# chown nobody:nobody /var/mod_pagespeed/*
  10.  root@server1[/usr/src/mod_pagespeed]# /usr/local/apache/bin/apxs -c -i /home/cpeasyapache/src/httpd-2.2.22/modules/filters/mod_deflate.c  —-> Enable mod_deflate (required for mod_pagespeed)
  11. root@server1[/usr/src/mod_pagespeed]# vim /usr/local/apache/conf/pagespeed.conf —>edit the mod_pagespeed configuration file

In this file include

                                  1. LoadModule pagespeed_module modules/mod_pagespeed.so

                                  2. LoadModule deflate_module modules/mod_deflate.so

                                  3. ModPagespeedFileCachePath “/var/mod_pagespeed/cache/”

                                  4. ModPagespeedGeneratedFilePrefix “/var/mod_pagespeed/files/”

And then open /usr/local/apache/conf/includes/pre_main_global.conf and add:

Include conf/pagespeed.conf

# Rebuild Apache config and restart apache.

/scripts/buildhttpdconf

/etc/init.d/httpd restart

Once your web server fires up, it’ll be mod_pagespeed-enabled.

You can verify it by using any web-page test tool. Here I am using Pingdom tool. I have share the screenshots of with and without mod_pagespeed module.



Website without mod_pagespeed module





Website with mod_pagespeed module









Openstack Cloud Software

OpenStack : The Mission

“ To produce the ubiquitous Open Source Cloud Computing platform that will meet the needs of public and private cloud providers regardless of size, by being simple to implement and massively scalable.”

OpenStack is a collection of open source software projects that enterprises/service providers can use to setup and run their cloud compute and storage infrastructure.Rackspace and NASA are the key initial contributors to the stack. Rackspace contributed their “Cloud Files” platform (code) to power the Object Storage part of the OpenStack, while NASA contributed their “Nebula” platform (code) to power the Compute part. OpenStack consortium has managed to have more than 150 members including Canonical, Dell, Citrix etc.

There are 5 main service families under OpenStack

Nova         –   Compute Service

Swift         –    Storage Service

Glance      –    Imaging Service

Keystone  –    Identity Service

Horizon    –    UI Service

Open Stack Compute Infrastructure (Nova)

Nova is the Computing Fabric controller for the OpenStack Cloud. All activities needed to support the life cycle of instances within the OpenStack cloud are handled by Nova. This makes Nova a Management Platform that manages compute resources, networking, authorization, and scalability needs of the OpenStack cloud. But, Nova does not provide any virtualization capabilities by itself; instead, it uses libvirt API to interact with supported hypervisors. Nova exposes all its capabilities through a web services API that is compatible with the EC2 API of Amazon Web Services.

Functions and Features:

• Instance life cycle management

• Management of compute resources

• Networking and Authorization

• REST-based API

• Asynchronous eventually consistent communication

• Hypervisor agnostic : support for Xen, XenServer/XCP, KVM, UML, VMware vSphere and Hyper-V

OpenStack Storage Infrastructure (Swift)

Swift provides a distributed, eventually consistent virtual object store for OpenStack. It is analogous to Amazon Web Services – Simple Storage Service (S3). Swift is capable of storing billions of objects distributed across nodes. Swift has built-in redundancy and fail-over management and is capable of archiving and media streaming. It is extremely scalable in terms of both size (several petabytes) and capacity (number of objects).

Functions and Features

• Storage of large number of objects

• Storage of large sized objects

• Data Redundancy

• Archival capabilities – Work with large datasets

• Data container for virtual machines and cloud apps

• Media Streaming capabilities

• Secure storage of objects

• Backup and archival

• Extreme scalability

OpenStack Imaging Service (Glance)

OpenStack Imaging Service is a lookup and retrieval system for virtual machine images. It can be configured to use any one of the following storage backends:

• Local filesystem (default)

• OpenStack Object Store to store images

• S3 storage directly

• S3 storage with Object Store as the intermediate for S3 access.

• HTTP (read-only)

Functions and Features

• Provides imaging service

OpenStack Identity Service (Keystone)

Keystone provides identity and access policy services for all components in the OpenStack family. It implements it’s own REST based API (Identity API). It provides authentication and authorization for all components of OpenStack including (but not limited to) Swift, Glance, Nova. Authentication verifies that a request actually comes from who it says it does. Authorization is verifying whether the authenticated user has access to the services he/she is requesting for.

Keystone provides two ways of authentication. One is username/password based and the other is token based. Apart from that, keystone provides the following services:

• Token Service (that carries authorization information about an authenticated user)

• Catalog Service (that contains a list of available services at the users’ disposal)

• Policy Service (that let’s keystone manage access to specific services by specific users or groups).

Openstack Administrative Web-Interface (Horizon)

Horizon the web based dashboard can be used to manage /administer OpenStack services. It can be used to manage instances and images, create keypairs, attach volumes to instances, manipulate Swift containers etc. Apart from this, dashboard even gives the user access to instance console and can connect to an instance through VNC. Overall, Horizon

Features the following:

• Instance Management – Create or terminate instance, view console logs and connect through VNC, Attaching volumes, etc.

• Access and Security Management – Create security groups, manage keypairs, assign floating IPs, etc.

 • Flavor Management – Manage different flavors or instance virtual hardware templates.

 • Image Management – Edit or delete images.

 • View service catalog.

 • Manage users, quotas and usage for projects.

 • User Management – Create user, etc.

 • Volume Management – Creating Volumes and snapshots.

 • Object Store Manipulation – Create, delete containers and objects.

 • Downloading environment variables for a project.

INSTALLATING OPEN STACK

We can install open stack ESSEX very easily using StackGeek script. Login to your box and install git with apt-get. We’ll become root and do an update first.

sudo  su
apt-get update
apt-get install git

Now checkout the StackGeek scripts from Github:

git clone git://github.com/StackGeek/openstackgeek.git
cd openstackgeek

Install the Base Scripts

Be sure to take a look at the scripts before you run them. Keep in mind the scripts will periodically prompt you for input, either for confirming installation of a package, or asking you for information for configuration.

Start the installation by running the first script:

./openstack_base_1.sh

When the script finishes you’ll see instructions for manually configuring your network. You can edit the interfaces file by doing a:

vim /etc/network/interfaces

Copy and paste the network code provided by the script into the file and then edit:

auto eth0
iface eth0 inet static
  address 192.168.1.48
  network 192.168.1.0
  netmask 255.255.255.0
 broadcast 192.168.1.255
  gateway 192.168.1.124
  dns-nameservers 8.8.8.8
auto eth1

Change the settings for your network configuration and then restart networking and run the next script:

/etc/init.d/networking restart

Then run the second script :

./openstack_base_2.sh

After the second script finishes, you’ll need to set up a logical volume for Nova to use for creating snapshots and volumes. Nova is OpenStack’s compute controller process.

Here’s the output from the format and volume creation process:-

root@manager-System-Product-Name:/openstackgeek# fdisk /dev/sda
Device contains neither a valid DOS partition table,nor Sun,SGI or OSF disklabel
Building a new DOS disklabel with disk identifier 0xb39fe7af.
Changes will remain in memory only, until you decide to write them.
After that, of course, the previous content won't be recoverable.

Warning: invalid flag 0x0000 of partition table 4 will be corrected by w(rite)

Command (m for help): n
Partition type:
   p   primary (0 primary, 0 extended, 4 free)
   e   extended
Select (default p): p Partition number (1-4, default 1): 3
First sector (2048-62914559, default 2048):
 Using default value 2048 Last sector,(2048-62914559,default 62914559):
Using default value 62914559
Command (m for help): w The partition table has been altered!
Calling ioctl() to re-read partition table. Syncing disks.
root@manager-System-Product-Name:/openstackgeek# pvcreate -ff /dev/sda3
 Physical volume "/dev/sda3" successfully created
root@manager-System-Product-Name:/openstackgeek# vgcreate nova-volumes /dev/sda3
 Volume group "nova-volumes" successfully created

Note: Your device names may vary.

Installing MySql

The OpenStack components use MySQL for storing state information. Start the install script for MySQL by entering the following:

./openstack_mysql.sh

You’ll be prompted for a password used for each of the components to talk to MySQL:
Enter a password to be used for the OpenStack services
to talk to MySQL (users nova, glance, keystone): redhat
Note(Here “redhat” is the password given to nova,glance,keystone)

During the installation process you will be prompted for a root password for MySQL. In our install example we use the same password, ‘redhat’. At the end of the MySQL install you’ll be prompted for your root password again.

mysql start/running, process 8796
################################################################################
Creating OpenStack databases and users.
Use your database password when prompted.
 Run './openstack_keystone.sh' when the script exits.
################################################################################
Enter password:
After MySQL is running, you should be able to login with any of the OpenStack
users and/or the root admin account by doing the following:

mysql -u root -predhat
mysql -u nova -predhat nova
mysql -u keystone -predhat keystone
mysql -u glance -predhat glance

Installing Keystone

Keystone is OpenStack’s identity manager. Start the install of Keystone by doing:

./openstack_keystone.sh

You’ll be prompted for a token, the password you entered for OpenStack’s services, and your email address. The email address is used to populate the user’s information in the database.

Enter a token for the OpenStack services to auth wth keystone: redhattoken
Enter the password you used for the MySQL users (nova, glance, keystone):redhat
Enter the email address for accounts(nova,glance,keystone):user@company.com
You should be able to query Keystone at this point.
You’ll need to source the“stackrc” file before you talk to Keystone:
 . ./stackrc
 keystone user-list
 Keystone should return a list of users:
+----------------------------------+---------+------------------------+--------+
|                id                | enabled |         email          |  name  |
+----------------------------------+---------+------------------------+--------+
| b32b9017fb954eeeacb10bebf14aceb3 | True    | user@company.com       | demo   |
| bfcbaa1425ae4cd2b8ff1ddcf95c907a | True    | user@company.com       | glance |
| c1ca1604c38443f2856e3818c4ceb4d4 | True    | user@company.com       | nova   |
| dd183fe2daac436682e0550d3c339dde | True    | user@company.com       | admin  |
+----------------------------------+---------+------------------------+--------+

Installing Glance

Glance is OpenStack’s image manager. Start the install of Glance by doing:

./openstack_glance.sh

The script will download an Ubuntu 12.04 LTS cloud image from StackGeek’s S3 bucket.Once it’s done, you should be able to get a list of images:

glance index

Here’s the expected output:

ID              :- 71b8b5d5-a972-48b3-b940-98a74b85ed6a
Name            :- Ubuntu 12.04 LTS
Disk Format     :- qcow2
Container Format:- ovf
Size            :- 226426880

Installing Nova

We’re almost done installing! The last component is the most important one as well. Nova is OpenStack’s compute and network manager. It’s responsible for starting instances, creating snapshots and volumes, and managing the network. Start the Nova install by doing:

./openstack_nova.sh

You’ll immediately be prompted for a few items, including your existing network interface’s IP address, the fixed network address, and the floating pool addresses:

######################################################
The IP address for eth0 is probably 192.168.1.48.
Keep in mind you need an eth1 for this to work.
######################################################
Enter the primary ethernet interface IP: 192.168.1.48
Enter the fixed network (eg. 10.0.2.32/27): 192.168.1.0/24
Enter the fixed starting IP (eg. 10.0.2.33): 192.168.1.1
############################################################################
The floating range can be a subset of your current network.
Configure your DHCP server to block out the range before you choose it here.
An example would be 10.0.1.224-255
############################################################################
Enter the floating network (eg. 10.0.1.224/27):
Enter the floating netowrk size (eg. 32):

The fixed network is a set of IP addresses which will be local to the compute nodes. Think of these addresses as being held and routed internally inside any of the compute node instances.

The floating network is a pool of addresses which can be assigned to the instances you are running. For example, you could start a web server and map an external IP to it for serving a site on the Internet.


Finish Installing Nova

Nova should finish installing after you enter all the network information. When it’s done, you should be able to get a list of images from Glance via Nova:

 nova image-list

And get the expected output we saw earlier from Glance:

root@manager-System-Product-Name:/openstackgeek# nova image-list
+--------------------------------------+------------------+--------+--------+
|                  ID                  |       Name       | Status | Server |
+--------------------------------------+------------------+--------+--------+
| 71b8b5d5-a972-48b3-b940-98a74b85ed6a | Ubuntu 12.04 LTS | ACTIVE |        |
+--------------------------------------+------------------+--------+--------+

Installing Horizon

Horizon is the UI and dashboard controller for OpenStack. Install it by doing:

./openstack_horizon.sh

When it’s done installing, you’ll be given a URL to access the dashboard.
You’ll be able to login with the user ‘admin’
and whatever you entered earlier for your password.
If you’ve forgotten it, simply grep for it in your environment:

env |grep OS_PASSWORD

The URL will be : http://192.168.1.48

You can login the Openstack dashboard by the following credentials

USER : admin

PASSWORD : redhat
